Silk Screen Printing 16kw Air to Water Heat Pump for Eco-Friendly Home Heating System

Name: Silk Screen Printing 16kw Air to Water Heat Pump for EcoFriendly Home Heating System
Brand: DUHM
Price: 1 USD

Quality Silk Screen Printing 16kw Air to Water Heat Pump for Eco-Friendly Home Heating System for sale

Place of Origin : China

Brand Name : DUHM

Model Number : DHAM-16SIC

Price : Negotiable

Certification : CE

MOQ : 2

Packaging Details : Polywood Pallet

Delivery Time : 25 working day

Payment Terms : T/T,L/C AT SIGHT

Supply Ability : 800 Sets/Day

After-sales Service Provided : Free spare parts

Warranty : 1 Year

Operating Language : English, German, French, Dutch, Spanish

Application : Hotel, Garage, Commercial, Household

Power Source : Electric

App-Controlled : Yes

logo/pattern : Silk screen printing

Type : Air Source Heat Pump, Monoblock

Installation : Freestanding

Storage / Tankless : Instant / Tankless

Use : Home

Product Name : R290 Monoblock with EVI Heat Pump

Heating Source : Air to Water Heat Pump

Function : Heating+Cooling+ DHW

Refrigerant : R290

Housing Material : Galvanized Steel with Powder coated

Heating Capacity(A7/6℃,W 30/35℃) (kW) : 6.8~17.8

Power Supply : 220~240V/1/50Hz/60Hz

ErP Rating (35℃/55℃) : A+++/A++

Compressor : DC Rotary

Contact Now

Silk Screen Printing 16kw Air to Water Heat Pump for Eco-Friendly Home Heating System

Model	DHAM-08SIC	DHAM-10SIC	DHAM-12SIC	DHAM-16SIC	DHAM-20SIC
Heating Condition-Ambient Temp. (DB/WB): 7/6℃, Water Temp. (In/Out): 30/35℃
Heating Capacity Range (kW) )	2.8~10.8	3.8~11.8	4.8~13.8	6.8~17.8	8.8~22.8
Heating Power Input Range (kW)	0.51~2.2	0.7~2.5	0.8~2.8	1.2~3.7	1.6~5.0
COP (W/W)	4.8~5.5	4.7~5.4	4.9~5.7	4.7~5.4	4.5~5.3
Cooling Condition-Ambient Temp. (DB/WB): 35/24℃, Water Temp. (In/Out):12/7℃
Cooling Capacity Range (kW)	2.1~8.1	2.9~8.9	3.6~10.4	5.1~13.4	6.6~17.1
Cooling Power Input Range (kW)	0.6~2.9	0.8~3.2	1.0~3.5	1.5~4.7	2.0~6.1
EER (W/W)	2.8~3.4	2.8~3.4	2.9~3.5	2.8~3.3	2.8~3.2
Hot Water Condition -Ambient Temp. (DB/WB): 20/15℃,Water Temp. (In/Out): 15/55℃
Heating Capacity Range (kW)	3.4~13.0	4.6~14.2	5.8~15.9	8.2~20.5	10.6~26.2
Heating Power Input Range (kW)	0.6~2.7	0.8~3.2	1.0~3.3	1.5~4.5	2.0~5.8
COP (W/W)	4.7~5.4	4.5~5.3	4.7~5.6	4.5~5.4	4.5~5.3
ErP Rating (35℃/55℃)	A+++/A++
Operating Ambient Temperature (℃)	-25~43
Max Outlet Water Temperature (℃)	75
Sound Pressure (1m) (dB(A))	48	48	52	54	56
Water System Data
Pipework Size (inch)	G1.25''
Water Flow (m³/h)	1.4	1.7	2.1	2.8	3.4
Water Pressure Drop (max.) (kPa)	15	15	25	25	35
Circulation Pump Water Head (m)	7.5	7.5	9.0	9.0	11.0
Electrical System Data
Power Supply	220-240V/1/50Hz
Max. Power Input (kW)	3.30	3.75	4.20	5.55	7.50
Max. Current Input (A)	15.10	17.16	19.22	25.40	34.32
Fuse Rating (A)	16	20	20	32	40
Key Components
Refrigerant R290 (kg)/CO2 Equivalent (Ton)	1.1/0.0033	1.1/0.0033	1.5/0.0045	1.6/0.0048	1.6/0.0048
GWP	3
Compressor	DC Rotary Compressor
Fan Motor	DC Motor
Circulation Pump	1
*Unit Dimension(LWH) (mm)*	1155505855			1175505980		11755051445
*Shipping Dimension(LWH) (mm)*	1190510980			12055101105		12105401570
Net Weight /Gross Weight (kg)	120/130	120/130	130/140	135/145	170/185

Model	DHAM-12TIC	DHAM-16TIC	DHAM-20TIC	DHAM-25TIC
Heating Condition-Ambient Temp. (DB/WB): 7/6℃, Water Temp. (In/Out): 30/35℃
Heating Capacity Range (kW) )	4.8~13.8	6.8~17.8	8.8~22.8	10.8~27.8
Heating Power Input Range (kW)	0.8~2.8	1.2~3.7	1.6~5.0	2.0~6.3
COP (W/W)	4.9~5.7	4.7~5.4	4.5~5.3	4.4~5.3
Cooling Condition-Ambient Temp. (DB/WB): 35/24℃, Water Temp. (In/Out):12/7℃
Cooling Capacity Range (kW)	3.6~10.4	5.1~13.4	6.6~17.1	8.1~19.5
Cooling Power Input Range (kW)	1.0~3.5	1.5~4.7	2.0~6.1	2.6~7.5
EER (W/W)	2.9~3.5	2.8~3.3	2.8~3.2	2.6~3.1
Hot Water Condition -Ambient Temp. (DB/WB): 20/15℃,Water Temp. (In/Out): 15/55℃
Heating Capacity Range (kW)	5.8~15.9	8.2~20.5	10.6~26.2	13.0~32.0
Heating Power Input Range (kW)	1.0~3.3	1.5~4.5	2.0~5.8	2.4~6.9
COP (W/W)	4.7~5.6	4.5~5.4	4.5~5.3	4.6~5.3
ErP Rating (35℃/55℃)	A+++/A++
Operating Ambient Temperature (℃)	-25~43
Max Outlet Water Temperature (℃)	75
Sound Pressure (1m) (dB(A))	52	54	56	58
Water System Data
Pipework Size (inch)
Water Flow (m³/h)	2.1	2.8	3.4	4.3
Water Pressure Drop (max.) (kPa)	25	25	35	40
Circulation Pump Water Head (m)	9.0	9.0	11.0	11.0
Electrical System Data
Power Supply	380-415V/3/50Hz
Max. Power Input (kW)	4.20	5.55	7.50	9.45
Max. Current Input (A)	4.77	6.30	8.52	10.73
Fuse Rating (A)	8	8	10	16
Key Components
Refrigerant R290 (kg)/CO2 Equivalent (Ton)	1.5/0.0045	1.6/0.0048	1.6/0.0048	1.8/0.0054
GWP	3
Compressor	DC Rotary Compressor
Fan Motor	DC Motor
Circulation Pump	1
*Unit Dimension(LWH) (mm)*	1175505980			11755051445	11755051640
*Shipping Dimension(LWH) (mm)*	12055101105			12105401570	12105401765
Net Weight /Gross Weight (kg)	130/140	135/145	170/185	180/195

R290/R32 Monoblock Heat Pump For House Heating ,

Cooling And Domestic Hot Water Supply.

Providing continuous spacing heating /cooling and hot water supply. The wotech R290 & R32 series multi-function heat pump has a range of benefits which sets it apart from the competition,including the unique designed fan housing. It significantly increased the airflow of the heat pump, making it more efficient, energy-saving, and environmentally friendly.

High Efficiency Level A+++/A++

Wotech R290 & R32 monoblock heat pump has passed the Erp A+++/A++ energy class test of Intertek

FAQ

1)Are you a manufacturer?

Yes, we are a company and factory integrating R&D, production, and sales. At present, Wotech has three production bases in Shunde, Zhaoqing and Heyuan, Covering covering 100, 000 square meters.

2)Why should you select our heat pumps over those of other manufacturers?

We have more than 19 years of experience in the heat pump field. Besides, we have a professional technical team, the industry's top heat pump laboratory, and automatic production lines. We can meet your diverse order requirements.

3)Do you offer OEM/ODM customised services?

Yes. We are able to produce European-standard heat pumps under your brand according to your special needs.

4)Can you provide a sample service?

Yes, we are able to provide sample services.

5)How can we guarantee product quality?

With many years of heat pump export experience, we set up a top international quality control system to achieve the belief of making the best quality heat pumps for global user.
